Dual Bosch -200 Fuel Pumps with black bracket
Dual Bosch -200 Fuel Pumps with black bracket £299.00
Kit with two Bosch -200 fuel pumps and SPD double bracket.Bosch 0580464200 fuel pump(Bosch original, no copy)Flows: 275 liters / h at 5bar / pumpEnough for about 1100hp on the E85Input connection: M18 x 1.5Output connection: M12 x 1.5 (Check valve). M14 x 1.5 (Without check valve)Diameter: 60mmVoltage 12V
Bosch Motorsport E-Throttle 82mm
Bosch Motorsport E-Throttle 82mm £155.00
Electronic Throttle Body (82mm bore)Description- 82mm Bore size- Dual potentiometer redundancy- OE quality and performance-Includes groove on inlet port flange- Use mating connector D 261 205 358-01SpecificationsApplication and model suitability:- Generic use- Custom applications- Requires electronic accelerator pedal or mechanical pedal with integrated sensors and ECU capable of running ETC
Bosch Motorsport E-Throttle 74mm
Bosch Motorsport E-Throttle 74mm £155.00
Electronic Throttle Body (74mm bore)Description- 74mm Bore size- Dual potentiometer redundancy- OE quality and performance-Includes groove on inlet port flange- Use mating connector D 261 205 358-01SpecificationsApplication and model suitability:- Generic use- Custom applications- Requires electronic accelerator pedal or mechanical pedal with integrated sensors and ECU capable of running ETCPin 1 A - Motor -Pin 2 B - Pot -Pin 3 C - Pot +Pin 4 D - Motor +Pin 5 E - Pot 2Pin 6 F - Pot 1
Bosch Motorsport E-Throttle 68mm
Bosch Motorsport E-Throttle 68mm £155.00
Electronic Throttle Body (68mm bore)Description- 68mm Bore size- Dual potentiometer redundancy- OE quality and performance-Includes groove on inlet port flange- Use mating connector D 261 205 358-01SpecificationsApplication and model suitability:- Generic use- Custom applications- Requires electronic accelerator pedal or mechanical pedal with integrated sensors and ECU capable of running ETCPin 1 A - Motor -Pin 2 B - Pot -Pin 3 C - Pot +Pin 4 D - Motor +Pin 5 E - Pot 2Pin 6 F - Pot 1
Bosch 200 Fuel Pump ( Bosch 044 Replacement )
Bosch 200 Fuel Pump ( Bosch 044 Replacement ) £140.00
This is Bosch's new high performance fuel pump that replaces the classic Bosch -044 fuel pump! This fuel pump flows about 15% more and weighs about 15% less than the old -044 pump. This fuel pump is also made to handle Ethanol (E85) better unlike the old -044 pump.This is a direct replacement for you who want to replace an old -044 pump with something better.Specifications:275 L / H at 5 barMax working pressure 8barInlet: M14x1.5, M18x1.5 with supplied adapter.Outlet: M10x1 without non-return valve, M12x1.5 with supplied check valve.Consumption 17A at 5bar @ 13VBuilt-in pre-filter of 130 microns (non-replaceable)Power connection: M5 (-), M4 (+)Diameter: 52mm / 60mm if you use the included adapter so it fits directly in mounts for 60mm such as. Bosch -044 uses.Fuel: Petrol, Ethanol and Diesel. The fuel pump will have a shorter life on Ethanol than on petrol and Diesel.Voltage: 12VCan be mounted both inside and outside the tank.
Bosch Combined Pressure and Temperature Sensor
Bosch Combined Pressure and Temperature Sensor £99.50
Genuine Bosch pressure and temperature sensor PST-F 1  Robust design and stainless steel diaphragm making it usable for fuel and oil. Thread M10x1mm Supplied with mating connector
Bosch LSU49 Wideband Lambda Sensor
Bosch LSU49 Wideband Lambda Sensor £90.00
This sensor is designed to measure the proportion of oxygen in exhaust gases of automotive engines (gasoline or Diesel). The wideband lambda sensor LSU 4.9 is a planar ZrO2 dual cell limiting current sensor with integrated heater. Its monotonic output signal in the range of lambda 0.65 to air makes the LSU 4.9 capable of being used as a universal sensor for lambda 1 measurement as well as for other lambda ranges. The connector module contains a trimming resistor, which defines the characteristic of the sensor. The main benefit of the LSU 4.9 is the robust design combined with the high Bosch production quality standard. Sensor is compatible with the EMU Black. Proper installation and usage of the sensor is required to extend the sensor life. We cannot be held responsible for sensor failures. Includes Connector
Bosch 980cc Fuel Injector
Bosch 980cc Fuel Injector £47.00
Bosch 980cc Fuel Injector Technical specifications: - Name: 980cc- Flow @3 bar according to Bosch test environment: 670g / 980cc / 980cm3- Resistance: 12 ohm.- Spray pattern: 30 degree conical- Injector nozzle: long (xT)- Connector: Standard Bosch EV1 JPT Minitimer Jetronic- O-ring seals made of Viton.- E85 / M100 compatible and can withstand other common fuels due to the stainless steel internal parts. NOTE! if the injector is to be used with methanol, it must be flushed with gasoline after use.- Part number: 0 280 158 040- Reference numbers: 0280158040, EV-14- Price per injector Static max flow in test environment: 29 PSI (2 bar) 720cc / min = 69 lb / h43,5 PSI (3 bar) 900cc / min = 86 lb / h58 PSI (4 bar) 1038cc / min = 99 lb / h78,5 PSI (5 bar) 1170cc / min = 111 lb / h88 PSI (6 bar) 1284cc / min = 122 Ib / h101,5PSI (7bar) 1344cc / min = 128 lb / h
Bosch 870cc Fuel Injector
Bosch 870cc Fuel Injector £44.00
Bosch 870cc Fuel Injector Technical specifications:- Name: 870cc- Resistance: 12 ohm.- Spray pattern: 30 degree conical- Injector nozzle: long (xT)- Connector: Standard Bosch EV1 JPT Minitimer Jetronic- O-ring seals made of Viton.- E85 / M100 compatible and can withstand other common fuels due to the stainless steel internal parts. NOTE! if the injector is to be used with methanol, it must be flushed with gasoline after use.- Part number: 0 280 158 209- Reference numbers: 0280158209, EV-14- Price per injectorStatic max flow in test environment:29 PSI (2 bar) 672cc / min = 64 lb / h43,5 PSI (3 bar) 864cc / min = 82 lb / h58 PSI (4 bar) 972cc / min = 93 lb / h78,5 PSI (5 bar) 1098cc / min = 105 lb / h88 PSI (6 bar) 1218cc / min = 116 Ib / h101,5PSI (7bar) 1320cc / min = 126 lb / h
Bosch 630cc Fuel Injector
Bosch 630cc Fuel Injector £40.00
Bosch 630cc Injector Technical specifications:- Name: 630cc- Resistance: 12 ohm.- Spray pattern: 30 degree 2 jets- Injector nozzle: long (xT)- Connector: Standard Bosch EV1 Minitimer Jetronic- O-ring seals made of Viton.- E85 / M100 compatible and can withstand other common fuels due to the stainless steel internal parts. NOTE! if the injector is to be used with methanol, it must be flushed with gasoline after use.- Part number: 0 280 158 123- Reference numbers: 0280158123, EV-14-ST-OEM nummer:997 605 132 00997 605 132 01997 605 132 02- Price per injectorStatic max flow in test environment:29 PSI (2 bar) 492cc / min = 47 lb / h43,5 PSI (3 bar) 612cc / min = 58 lb / h58 PSI (4 bar) 708cc / min = 67 lb / h78,5 PSI (5 bar) 738cc / min = 70 lb / h88 PSI (6 bar) 870cc / min = 83 Ib / h101,5PSI (7bar) 942cc / min = 90 lb / h
Bosch Knock Sensor
Bosch Knock Sensor £40.00
Bosch Knock Sensor  Sensor pinout: Pin 1 Sig+ / Pin 2 Sig- /  Pin 3 Scr Mating connector Included
Bosch 550cc Fuel Injector
Bosch 550cc Fuel Injector £35.00
Bosch 550cc injector Technical specifications:- Name: 550cc- Resistance: 12 ohm.- Spray pattern: 30 degree 2 jets- Spray angle: 15 degrees 270 degree twist (connector as reference point)- Connector: Bosch Uscar- E85 / M100 compatible and can withstand other common fuels due to the stainless steel internal parts. NOTE! if the injector is to be used with methanol, it must be flushed with gasoline after use.- O-ring seals made of Viton.- Measurement between O-ring seals: 48,65 mm- Part number: 0 280 158 117- Reference numbers: 0280158117 , EV-14-ES- OEM Numbers:7R3V-9F593-A5B7R3Z-9F593-AA7R3Z9F593AAFC7R3Z9F593AA- Price per injectorStatic max flow in test environment:29 PSI (2 bar) 420cc / min = 40 lb / h43,5 PSI (3 bar) 510cc / min = 49 lb / h58 PSI (4 bar) 588cc / min = 56 lb / h78,5 PSI (5 bar) 657cc / min = 63 lb / h88 PSI (6 bar) 732cc / min = 70 Ib / h101,5PSI (7bar) 792cc / min = 75 lb / h
Bosch Green Fuel Injector 465cc
Bosch Green Fuel Injector 465cc £35.00
Bosch 465cc "green" injectors Technical specifications:- Name: 465cc- Resistance: 12,2 ohm.- Spray pattern: 30 degree 2 jets- Connector: Standard Bosch EV1 Minitimer Jetronic- O-ring seals made of Viton.- Part number: 0 280 155 968- Reference numbers: 0280155968 , EV-6-E- Price per injectorStatic max flow in test environment:29 PSI (2 bar) 356cc / min = 34 lb / h43,5 PSI (3 bar) 430cc / min = 41 lb / h58 PSI (4 bar) 492cc / min = 47 lb / h78,5 PSI (5 bar) 555cc / min = 53 lb / h88 PSI (6 bar) 606cc / min = 58 Ib / h101,5PSI (7bar) 666cc / min = 63 lb / h(55 PSI (3,8 bar) 480cc / min = 46 lb / h) Price per Injector
Bosch 026 Fluid Temperature Sensor
Bosch 026 Fluid Temperature Sensor £25.00
This sensor is designed to measure fluid temperatures e.g.oil, water or fuel. This signal may be used as a control value for engine control units or as a measurement value which is logged in a data acquisition system.  M12x 1.5 thread. Mating connector included
